Opis

Stable positions number 3-position
Contacts configuration SP3T
Switching method ON-OFF-ON
AC contacts rating
(at resistance load) 15 A / 250 VAC
Key button colour black
Max. contact resistance: 35m?
Body colour black
Operating temperature -30...80°C
Leads 6.3x0.8mm connectors
Electrical life 10000cycles
Mounting hole diameter 30.3 x 10.6mm
Number of positions 3
Button marking --O=

tehnički podaci:
- Plug connection: 6.8 x 0.8 mm
Peak switch-on current: max. 150 A
Approvals: ENEC, UL, CSA
Type C1520 VB AAB
Switching current 16 A
Specification 1-pole On/Off/On
Breaking capacity 16 (4) A/250 Vac
Switching voltage 250 Vac
Functions Maintained-0-Maintained
Front panel thickness 0.75 - 2.5 mm
Printed I/O/II
Front panel cut-out 30 x 11 mm
Switch position SPDT, On-Off-On
Housing schwarz
Material Polyamide 6.6
Content 1 Units
RoHS compliant yes
