The UNI-T UDP3305-E is a linear DC power supply which features a total of four channels, and a power output of 348 W. The first two channels are both 32 V / 5 A and have the option of being internally connected in either series or parallel operation.
The third channel of the UDP3305 can be set to 6 V / 3 A and the fourth channel is a fixed 5 V USB output, with a maximum current of 2 A.

This power supply sets itself apart from other competitors because of its high price to quality ratio, as it comes with a readback resolution of 10 mV / 1mA, in combination with features such as real-time waveform display and extensive connectivity capabilities with USB, RS232, LAN and digital I/O. Furthermore, the UTD3305-E supports SCPI, which makes it possible to program the power supply.
In addition, it is possible to power each channel on or off individually, and the large 4.3in display gives a detailed overview of up to 3 channels at the same time.
It is because of these features that the UDP3305-E can compete with other popular power supplies, such as the Rigol DP832 and the Siglent SPD3303X-E.

Specifications
Output switchEach channel
Voltage rangeCH1: 0 - 32 V
CH2: 0 - 32 V
CH3: 0 - 6 V
CH4: 5 V
Current rangeCH1: 0 - 5 A
CH2: 0 - 5 A
CH2: 0 - 3 A
CH2: 2 A
Ripple? 350 µ V / 2 mA
ProtectionOCP, OVP, OTP
InterfacesUSB host/device, LAN, RS232, Digital IO
Display4.3in TFT
Dimensions355 x 240 x 168 mm
Weight10.2 kg
