Opis

radni napon 12V
struja 1 A, 28 V DC / 0,5 A, 120 V AC
dimenzije 20,0x9,8x12 mm

Contact: DPDT
Contact Material:Gold Overlay Silver Alloy
Rated Current:2A
Min. Switching Current:0,01mA / 10mV DC
Switching Voltage (AC/DC):250VAC / 220VDC
Max. Switching Power:62,5VA / 30W
Operate/Release Time:6/4ms
Testing Voltage
Coil/Contact:1500V AC
Contact/Contact:1000V AC
Lifetime
Mechanical:1x108 Operations
Electrical: 2x105 Operations
Operating Temperature:-40...+85°C
Weight Approx.:1,5g
