Opis

Manufacturer SUNON
Type of fan DC
Kind of fan axial
Supply voltage 5V DC
Fan dimensions 40x40x10mm
Power consumption 800mW
Current rating 120mA
Fan efficiency 11.99m3/h
Noise level 23dBA
Kind of Bearing slide bearing
Rotational rate/speed 6100rpm
Weight 15.6g
Current and power consumption tolerance ±15%
Min. insulation resistance 10M?
Impeller material thermoplastic
Enclosure material thermoplastic
Insulation class A
Leads 2 leads
Operating temperature -10...70°C
Cable length 300mm
Static pressure 3.05mm H2O
Fan motor brushless DC motor
Flammability rating UL94V-0
Operating voltage 3.5...6V
Wire size 26AWG
