Opis

Stable positions number 2-position
Contacts configuration SPST x2
Switching method ON-OFF + ON-OFF
AC contacts rating
(at resistance load) 10 A / 250 VAC
Key button colour red
Illumination neon lamp 230V
Max. contact resistance: 50m?
Flammability rating UL94V-2
Operating temperature -20...85°C
Leads 6.3x0.8mm connectors
Panel thickness max 3mm
Mounting hole diameter 30.2 x 22.2mm
Number of positions 2
Button marking blank
Backlight colour red
Body material polyamide
Body dimensions 32 x 22 x 26.6mm
Test voltage 1.5kV
tehnički podaci:
-Switch type ROCKER
Stable positions number 2-position
Contacts configuration SPST x2
Switching method ON-OFF + ON-OFF
AC contacts rating
(at resistance load) 10 A / 250 VAC
Key button colour red
Illumination neon lamp 230V
Max. contact resistance: 50m?
Flammability rating UL94V-2
Operating temperature -20...85°C
Leads 6.3x0.8mm connectors
Panel thickness max 3mm
Mounting hole diameter 30.2 x 22.2mm
Number of positions 2
Button marking blank
Backlight colour red
Body material polyamide
Body dimensions 32 x 22 x 26.6mm
Test voltage 1.5kV
