Opis

• Long operating life due to high precision mechanism design
• 4,8mm flat cable plug
• 16A current

Switching Capacity:16A, 250V AC/0,6A, 125V DC
Contact Resistance, Max.:50mW
Isolation Resistance (500V DC), Min.:100MW
Dielectric Strength, Min.:1000V AC

Operating Temperature:-25...+80°C
Operating Force, Max.:3,92N

Operating Life
mechanical:50x106 Switches
electrical:10x104 Switches
Air Humidity:85% RH
Vibration Test (10...55Hz):1,5mm Amplitude
