Opis

Specifications
Cijena za 1 metar !
number of conductors: 10
pitch: 1/2in (1.27mm)
colour: grey
length: 100ft (30.48m)
conductor:
stranded
size: AWG28
number of strands per conductor: 7 x 0.127mm
space between the strands of the various conductors: min. 1.27mm
cross section: 156 mil2
insulation:
insulation material: PVC grey
average insulation thickness: 9 mil
min. insulation thickness: 7mil
electrical characteristics:
spark test: 2500V
dielectric strength test: min. 2kV in 1 minute
conductor resistance: max. 237ohm/km
insulation resistance: min. 1Gohm/m
capacity: 40pF/m
inductance: 1.45mH
impedance: 100ohm
propagation: 4.2ns/m
UL grade
UL no : E162690
UL style : 2651
rated temperature : 105°C
rated voltage : 300V
flame test : VW-1
CSA grade
CSA no : LL103674
CSA standard : CC22.2 NO.210.2
rated temperature : 105°C
rated voltage : 300V
flame test : FT1, FT2
