Features
• Low profile (height 15,7mm)
• High sensitive coil: 400mW
• Dielectric strength between coil and contacts: 5kV
• Insulation: 10mm between coil and contacts
• Cadmium free contacts
• Protection class RTII

Technical Specifications

Contact:
FTRK1CK_: SPDT
FTRK1AK_: SPST-NO
Contact Material: AgSnO2
Rated Current: 16A
Max. Switching Current: 20A
Max. Switching Voltage: 440V AC / 300V DC
Max. Switching Power: 4000VA / 384W
Max. Operate/Release Time: 15/5ms

Testing Voltage
Coil/Contact (1Min.): 5000V AC
Opening Contact (1Min.): 1000V AC

Min. Lifetime
Mechanical: 20x106 Operations
Electrical (AC/DC)
FTRK1CK_: 50x103/30x103 Operations
FTRK1AK_: 100x103/100x103 Operations
Operating Temperature:-40...+85°C
Weight Approx.: 13g

Coil Data

Part Nr. UNUAnUAbPNRN
[V DC][V][V][mW][Ohm]
FTRK1CK005W 53,50,540062
FTRK1CK012W 128,41,2400360
FTRK1CK024W 2416,82,44001440
FTRK1AK005W 53,50,540062
FTRK1AK012W 128,41,2400360
FTRK1AK024W 2416,82,44001440

UN = Rated Voltage, UAn = Operate Voltage, UAb = Release Voltage, PN = Rated Power, RN = Coil Resistance; All Specifications Measured at 20°C
